Pneumatic vacuum switch
Pneumatic vacuum switch
Adjustable pneumatic vacuum switch, which thanks to a 2-way micro valve permits the opening or closing of a pneumatic passage. Particularly suitable for use with vacuum generators with compressed air for power management depending on the set vacuum.
| Art. SVC/LP | Art. SVC/LPA | |
|---|---|---|
| Campo di regolazioneAdjustment rangeVerstellbereich mbar ass. | 930 ÷ 50 | 900 ÷ 40 |
| Differenziale fissoFixed differentialFestes Differential mbar | 70 | 100 |
| RipetibilitàRepeatabilityWiederholbarkeit mbar | ±5 | ±5 |
| Segnale a riposoIdle signalRuhesignal | NC | NO |
| Pressione di alimentazioneWorking pressureVersorgungsdruck bar | 2 ÷ 8 | 2 ÷ 8 |
| Portata max della microvalvola a 6 barMax. capacity of 6 bar microvalveMax. Durchsatz Mikroventil bei 6 bar NI/min | 72 | 72 |
| Temperatura di lavoroWorking temperatureArbeitstemperatur °C | -10 ÷ +60 | -10 ÷ +60 |
| PesoWeightGewicht g | 104 | 102 |
